LANKO 701 CLAVEX

NON-SHRINK GROUT WITH HIGH PERFORMANCE

Lanko 701 Clavex is a ready-to-mix, self-levelling, shrinkage-compensating, fluid or semi-paste mortar intended for sealing and bedding purposes with high mechanical strength.

  • High Mechanical Strength (compressive strength can reach to 750 ksc at 28 days).
  • No Bleeding.
  • Very Good Flow.
  • Good dimensional stability.
  • Non toxic, non corrosive.
  • Ready and easy to use.
  • Impact resistant.
Where to buy
Product Data Sheet Safety Data Sheet Show all documents

Usage

  • Bedding of elements ranging in thickness from 25 mm. to 50 mm.
  • Suitable for the bedding of heavy machinery based, rail posts, structural column.
  • Sealing of steel rebar, tie rods, connectors (diaphragm walls) and anchoring bars.
  • Wedged keying of prefabricated elements.
  • Underpinning.
  • Grouting and filling gaps.


Advantages

  • High Mechanical Strength (compressive strength can reach to 750 ksc at 28 days).
  • No Bleeding.
  • Very Good Flow.
  • Good dimensional stability.
  • Non toxic, non corrosive.
  • Ready and easy to use.
  • Impact resistant.

Packaging

25 kg bag.

Pallet containing 56 x 25 kg bags (1,400 kg)

Product Details

Product Information

Shelf life

12 months from date of production stored properly in undamaged, original, sealed packaging.

Storage conditions

Store in dry condition, protected from direct sunshine.
Technical Information

Compressive strength

Consistency

1 day

7 days

28 days

Pouring @15% water

≥ 25 MPa

≥ 55 MPa

≥ 75 MPa

Plastic @13% water

≥ 30 MPa

≥ 60 MPa

≥ 80 MPa

Flexural-strength

Consistency

1 day

7 days

28 days

Pouring @15% water

≥ 5 MPa

≥ 7 MPa

≥ 8 MPa

Plastic @13% water

≥ 6 MPa

≥ 8 MPa

≥ 9 MPa




Application

Application Information

Mixing ratio

Consistency

Aggreegate 3/8"

Water (Litres)

Pouring

-

3.75 - 4 (15-16% water)

Plastic-3.25 (13% water)

Micro Concrete

10 Litres

3.75 - 4 (15-16% water)

Ambient air temperature

10°C to 35°C

Setting time

Pouring Consistency

25°C

Initial Setting

~ 5 h

Final Setting~ 8 h
Plastic Consistency25°C
Initial Setting~ 4 h

Final Setting

~ 7 h
Consumption

Consumption

For 1 m3 of mortar approx. 75 x 25 kg bags.
Application steps

MIXING

1. Mix LANKO 701 CLAVEX with clean water.The quantity of water used depends on the consistency required.
2. Mixing should be carried out as follows: By machine mix with recommended speed at 500 rpm.
3. Mixing time: at least 3 minutes and required consistency is obtained.
4. Leave the mixture to stand for 1 - 3 minutes.
5. Do not add water after mixing.

Micro concrete Preparation
1. Micro-concrete is made up by adding 10 litres (16 kg) of clean 3/8" aggregate for each 25 kg bag of LANKO 701 CLAVEX as mention in above table.
2. Machine mix at least 3 minutes or until a plastic consistency is obtained.



APPLICATION

Bedding

1. The mixed grout should be placed promptly before it stiffens. Higher temperature will accelerate setting time.
2. Pour grout from one side only to avoid air entrapment.
3. Use a rod or strap to assist in large/difficult placement as well as to facilitate maximum surface contact. Concrete vibrator should not be used. Excessive vibration will cause separation of each ingredient.

Anchoring

1. Damp the area with water and clean out the area to be sealed.
2. Remove residual water just prior to sealing.
3. Fill the hole with mortar and insert anchoring bar into the hole and cast the mortar.

CLEANING OF EQUIPMENT

Clean all tools and equipment with water immediately after use. Hardened mortar can only be removed mechanically.
